Product Details
Place of Origin: China
Brand Name: HuiChi (HC)
Certification: API
Model Number: Drift Series
Payment & Shipping Terms
Minimum Order Quantity: 1 Set
Price: $ 100 ~ 250 / Set
Packaging Details: Export Wooden Case And Wooden Palle Or According To Customers' Requirements.
Delivery Time: Within 15-30 Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000 Sets Per Month
Condition: |
New |
Warranty Of Core Components: |
1 Year |
Customized: |
Logo / Packaging / Graphic |
Machinery Test Report: |
Provided |
Size: |
1 1/2" To 7" |
Connection: |
NC And TBG |
Usage: |
Detect The Pipe Size |
Material: |
Steel , Nylon |
Application: |
Drill Pipe, Casing, Tubing |
Length: |
500 Or As Your Request |
Condition: |
New |
Warranty Of Core Components: |
1 Year |
Customized: |
Logo / Packaging / Graphic |
Machinery Test Report: |
Provided |
Size: |
1 1/2" To 7" |
Connection: |
NC And TBG |
Usage: |
Detect The Pipe Size |
Material: |
Steel , Nylon |
Application: |
Drill Pipe, Casing, Tubing |
Length: |
500 Or As Your Request |
Sub Type Drift manufactured with threads on both top and bottom ends. The top end is connected with the drill string, while the bottom end is standby.
Bail Type Drift comprises of gauge plate and connecting rod.
Double Bail Drift for tubing or drill pipe is usually used on the ground. The shape of drift diameter gauge is a long cylindrical body with sucker rod thread on both ends. Drifting is done manually.
Thread gauges include ring gauges and plug gauges. Ring gauges detect external thread sizes, while plug gauges detect internal thread sizes. Both ring gauges and plug gauges have inspection tools for detecting the maximum and minimum limit sizes. Thread plug gauges are used for comprehensive inspection of internal threads, while thread ring gauges are used for comprehensive inspection of external threads. Thread gauges are tools for measuring the correctness of internal thread sizes. There are many types of thread gauges, which can be divided into three types based on their shapes: ordinary coarse pitch, fine pitch, and pipe thread. Plug gauges with a pitch of 0.35 mm or less, grade 2 accuracy and higher than grade 2 accuracy, and grade 3 accuracy with a pitch of 0.8 mm or less do not have end stop probes. Thread gauges below 100 mm are tapered shank thread gauges. Thread gauges above 100 mm are double shank thread gauges.
The products sold by our company mainly include various standard precision gauges including smooth plug gauges, smooth ring gauges, taper plug gauges, taper ring gauges, thread plug gauges, thread ring gauges, taper thread plug gauges, taper thread ring gauges, American standard ring gauges, American standard plug gauges, double handle trapezoidal thread ring gauges, double handle trapezoidal thread plug gauges, American standard special gauges for oil well pumps, special gauges for oil well pump threads, sucker rod thread gauges, non-thickened oil pipe gauges, external thickened oil pipe gauges , casing gauge, line pipe gauge, drill pipe gauge, pin plug gauge, sucker rod coupling, sucker rod coupling tap, smooth plug gauge, smooth ring gauge, table ring gauge, calibration ring gauge, American thread ring gauge, American thread plug gauge, American standard plug gauge, British ring gauge, British thread ring gauge, British plug gauge, British thread plug gauge, metric ring gauge, metric thread ring gauge, metric plug gauge, metric thread plug gauge, thread gauge, thread tooth gauge, thread stop gauge, etc. Our company has a complete range of products, reasonable design, stable structure, high precision, wear resistance and long service life. If you need, please contact us.
1.Designed and manufactured according to 5CT and 5DP;
2.Three types: tubing drift, casing drift and drill pipe drift;
3.Clean the inside of the pipes;
4.Test the diameter of downhole tubular;
5.Type: tubing drift, casing drift, drill pipe drift;
6.Size of tubular: 1.66 ~ 20 in (42.16~ 508mm).
Oil thread used in oil industry, according to using need subdivided into straight and taper, different type of tooth, the varieties, specifications, mainly divided into four categories:
1. Oil tool joint thread gauge, is testing oil drill pipe joints, drill pipe and drill collar, drill stem structure connection thread inspection gage;
2. Oil casing thread gauge;
3. Oil casing thread gauge;
4. Oil pipeline pipe thread gauge.
| Casing Drift (in) | 4 1/2 | 5 | 5 1/2 | 5 3/4 | 6 5/8 | 7 |
| O.D. (mm) | 92-95 | 102-107 | 114-118 | 119-128 | 136-148 | 146-158 |
| Length (mm) | 500 | 500 | 500 | 500 | 500 | 500 |
| Up Connection |
NC 26 2 3/8 TBG |
NC 26 2 7/8 TBG |
NC 31 2 7/8 TBG |
NC 31 2 7/8 TBG |
NC 31 2 7/8 TBG |
NC 38 3 1/2 TBG |
| Down Connection |
NC 26 2 3/8 TBG |
NC 26 2 7/8 TBG |
NC 31 2 7/8 TBG |
NC 31 2 7/8 TBG |
NC 31 2 7/8 TBG |
NC 38 3 1/2 TBG |
| Tubing Size (in) | 1 1/2 | 2 | 2 1/2 | 3 | 3 1/2 | 4 |
| O.D. (mm) | 38 | 48 | 59 | 73 | 73 | 95 |
| Length (mm) | 500 | 500 | 500 | 500 | 600 | 600 |
| Pipe Type | Specification | Drift Size | |
| Drift Size | Min. Dia. (mm) | ||
|
Casing |
≤ 8-5/8 9-1/8 ~ 13-3/8 ≥16 |
150 , 305 , 305 |
d-3.18 d-3.97 d-4.76 |
| Tubing | ≤ 2-7/8 ≥3-1/2 | 1067 , 1067 |
d-2.38 d-3.18 |
Iron box or iron frame , or customized according to customer requirements , or according to customer requirements.
100% tested before delivery.
Express, truck , train , air , sea , or customized according to customer requirements.
